MOTOR- 24 Volt DC
MOTOR SIZE -35 Watt
GEARBOX -Worm drive
GEARBOX RATIO- 96 to 1
PULL FORCE -10 Kgf
OPENINGS** -20 per Day
GATE/DOOR SPEED- 11 meter/ min
OBSTRUCTION SENSING -Electronic Adjustable in both directions independently
ACTIVATION N/O Electrical circuit
OTHER FEATURES
LED Display mode
IRB sensing connection
Mechanical override
Battery operated
Soft start and stop
Wall Console optional
Lock out function
On board receiver max 30 remotes
Courtesy light facility
GSM compatibility
BATTERY -2x12Volt (24V) 2.4 Ah
ELECTRICAL CONSUMPTION- 220-260 Volt / 150 Milli amps
DUTY CYCLE -75%
GUARANTEE MECHANICAL & WORKMANSHIP- 24 Months
ELECTRICAL -12 Months
PACKING DIMENSIONS (mm)
BOX WITH OPERATOR (mm) 400 x 220 x 190 = 6Kg
